Description
LS14500-CNA – AA-size Bobbin Cell with axial leads
Primary Li-SOCl2 cell
3.6V lithium thionyl chloride AA-size bobbin cell – 2.6Ah
Physical characteristics
Diameter: (max) 14.55 mm (0.57 in)
Height: (max) 50.3 mm (1.98 in)
Typical weight: 16.7 g (0.6 oz)
Li metal content approx.. 0.7 g
Benefits
Enhanced Capacity
High voltage response, stable during most of the lifetime of the application
Wide operating temperature range (- 60 °C / + 85 °C)
Low self-discharge compatible with long operating life (less than 1% after 1 year of storage at + 20 °C)
Superior resistance to corrosion
Easy integration into compact systems
Key features
Bobbin construction
Well controlled passivation
Hermetic construction with glass-to-metal seal
Stainless steel container
Non-flammable electrolyte
Non restricted for transport
RoHS and REACH compliance
Made in France, China, UK
Typical applications
Utility Metering
Automatic Meter Reading
Alarms and security devices
Memory Back-up
Tracking systems
Professional electronics
