Description
LC18650-26H Li-Ion Cell with protection circuit
3.7V 2600mAh
DIMENSIONS:
Length: 69mm
Diameter: 18mm
The protection circuit prevents overcharging and over discharging of the cell. These cells are perfect for use in torches, headlamps and so forth.
Electrical Characters
Charging Method: CC-CV
Charging Voltage: 4.2±0.03V
Over Charging Protection: 4.28±0.025V
Standard Charging Current: 520mA(0.2C)
Max. Charging Current: 2A
Cut-off Charging Current: 52mA(0.02C)
Standard Discharging Current: 520mA(0.2C)
Max. Continuous Discharge Current: 2A
Discharging cut-off Voltage: 2.8V
Over Discharge Current: 4-8A
Over Discharging Protect: 2.8±0.08V
Internal Resistance: <150m Ohm
Standard Charge Temperature: 0~45℃
Standard Discharge Temperature: -20~60℃
