Description
LS14500 – AA-size Bobbin Cell
Primary Li-SOCl2 cell 3.6V lithium thionyl chloride AA-size bobbin cell – 2.6Ah
Physical characteristics
Diameter: (max) 26.0 mm (1.02 in)
Height: (max) 50.4 mm (1.98 in)
Typical weight: 51 g (1.8 oz)
Li metal content approx.. 1.7 g
Benefits
Enhanced Capacity High voltage response, stable during most of the lifetime of the application
Wide operating temperature range (- 60 °C / + 85 °C)
Low self-discharge compatible with long operating life (less than 1% after 1 year of storage at + 20 °C)
Superior resistance to corrosion
Easy integration into compact systems
Key features
Well controlled passivation
Built-in safety vent
Finish with 5A fuse
Hermetic construction with glass-to-metal seal
Stainless steel container
Non-flammable electrolyte
Non restricted for transport
RoHS and REACH compliance
Made in France, China, UK
Typical applications
Radio communication and military applications
Automotive telematics
Alarms and security devices
Memory Back-up
Tracking systems
GPS
Sonobuoys
Beacons and emergency location transmitters
Pipeline inspection
