Description
Electrical Specifications
Nominal Voltage: 4.0v
Nominal Capacity:
After standard charging, 1C discharge to 2.75v at 25°C +/- 3°C
(C is the nominal capacity value under specified voltage)
720AS (180mAh) @ 3.67v
1260AS (350mAh) @ 3.90v
1368AS (380mAh) @ 4.00v
Max continuous Discharge Current: 2000mA
Max pulse Discharge Current: 5000mA
Discharge Cutoff voltage: 2.5v
Operating Temperature: -40°C to +85°C
Max. Energy: 1.9Wh
Weight: ≤ 22g
** Price is per capacitor **
